METRI-PACK 150 FEMALE TERMINAL 16-18 AWG

Metri-Pack 150 Female Terminal 16–18 Awg — Metri-Pack 150 Crimp Terminal

The 12161184 is a female crimp terminal for Metri-Pack 150 connector assemblies, rated for 16–18 AWG (0.82–1.31 mm²) wire. This terminal is the contact component that is crimped onto the wire conductor and inserted into the Metri-Pack 150 housing cavity, where it mates with the corresponding male contact in the mating connector to complete the electrical circuit. Correct crimp tooling and die selection for the Metri-Pack 150 terminal family is essential for a reliable, gas-tight crimp joint.

Metri-Pack 150 Terminal — Crimp Specification

Each terminal connector family requires the specific crimp tool and die designed for that terminal’s barrel geometry. Using incorrect tooling produces an inconsistently formed crimp that may appear acceptable but fails under vibration or thermal cycling. Consult the terminal manufacturer’s specification for the correct crimp tool and die number, conductor cross-section range, and insulation OD range for the 16–18 AWG gauge bracket.

Available from Arctic Performance Parts

Arctic Performance Parts stocks crimp terminals across all major motorsport connector families including Metri-Pack 150/280/630, Sumitomo TS/HX/MT/HW 090, Superseal 1.5, AmpSeal, GT150/GT280, and GM ECU connector series. Lead time 1–2 weeks for quantities beyond current stock.
