GT150 MALE TERM SEALED 18-16

Delphi GT150 Male Terminal Sealed 18-16 AWG – Mid-Gauge Male Contact for GT150 Plug-Side Wiring

The Delphi GT150 Male Terminal Sealed for 18-16 AWG wire (15326269) is a sealed male crimp contact for use on the plug side of Delphi GT 150 series connector assemblies. Covering the 18-16 AWG mid-gauge wire range, this male terminal is used in control signal outputs, relay coil feeds, solenoid driver circuits, and sensor supply connections on the plug side of GT150 connectors in motorsport harness builds across Norway, Sweden, and Denmark.

Mid-Gauge Male Terminal Role in GT150 Harnesses

In a GT150 connector pair, the male (plug side) terminals are often used at the harness branch termination points – where the wiring loom connects to a sensor, actuator, or module. The 18-16 AWG range covers circuits that require slightly more current capacity than fine-gauge signal wire but are still within the moderate-current band, such as solenoid valve feeds (boost control solenoids, VVTI actuators, idle air control), relay coil drive lines, and injector power reference feeds.

Build and Application Notes

• Used on plug (male connector body) side of GT150 assemblies
• Mates with GT150 female terminal (receptacle side)
• Compatible with GT150 TPA secondary locking devices
• Standard wire gauges: 18 AWG TXL/XLPE or 16 AWG TXL/XLPE
• Applications: Solenoid feeds, relay coil circuits, sensor supply rails

Specifications

• Part: 15326269
• Series: Delphi GT 150
• Terminal type: Male sealed crimp
• Wire gauge: 18–16 AWG
