Garrett Performance Intercoolers And Intercooler Cores Work Together With The Turbocharger As Part Of The Total Induction System. When Air Is Compressed In The Turbocharger It Yields A Lot Of Heat. The Job Of The Intercooler Is To Remove Heat From The Charge Air Making It More Dense. A Denser Charge Equals More Air And Fuel To The Engine And That Translates To More Horsepower Potential.
Key Features
- High Efficiency Bar And Plate Construction
- Vacuum Brazed Manufacturing For Durability
- Advanced Offset Fin Design For Greater Heat Transfer Effictiveness
- Air-To-Air Horizontal Flow Design
Product Specifications
Intercooler Cores
| Model | Air/Air |
|---|---|
| Flow Direction | Horizontal Flow |
| Engine HP | 375 |
| Engine HP Range | 300-400 |
| Length | Hot Flow (mm) | 254.00 |
| Length | Hot Flow (in) | 10.00 |
| Height | No Flow (mm) | 312.42 |
| Height | No Flow (in) | 12.30 |
| Width | Cold Flow (mm) | 114.30 |
| Width | Cold Flow (in) | 4.50 |
