Garrett CHRA Center Housing & Rotating Assembly – GTX2971R 90T turbine 54.1mm Comp Wheel
1 629$ Ink VAT
Available on backorder
Description
GTX2971R Garrett CHRA 836013-5003S
Power rating: 340 – 560 HP
Displacement: 1,8 – 3,0L
- Trim: 90
- Dual ceramic ball bearing assembly with metal cage
- Forged Milled Compressor Wheel
- Inconel Turbine Wheel
- Water- and Oil cooled
| Side | Specification | Value |
|---|---|---|
| Compressor Side | Inducer Ø | 54.10 mm |
| Exducer Ø | 71.40 mm | |
| Trim | 58 | |
| A/R | 0.60 | |
| Turbine Side | Inducer Ø | 56.50 mm |
| Exducer Ø | 54.00 mm | |
| Trim | 90 | |
| A/R | — |
