DEUTSCH SIZE 16 REMOVAL TOOL 14/16 GA

Deutsch Size 16 Removal Tool 14/16 GA (0411-291-1405) – Contact Extraction Tool for Deutsch Connectors

The Deutsch Size 16 Removal Tool (0411-291-1405) is a contact extraction tool for size 16 stamped contacts in 14/16 gauge applications. It lets harness builders across Norway, Sweden, and Denmark remove size 16 Deutsch contacts cleanly for re-pinning and servicing without damaging the connector.

How the Removal Tool Works

The tool is inserted into the connector cavity to release the contact’s locking finger, allowing the size 16 contact to be withdrawn from the rear. Using the correct size 16 tool protects both the contact and the housing, keeping the connector reusable after extraction.

Correct Use

This removal tool is intended for Deutsch stamped contacts in the size 16 / 14-16 gauge range. It is not designed for Mil-Spec or Autosport machined-contact connectors, which require their own dedicated tooling. Always match the tool to the connector series and contact size.

Specifications

• Brand: Deutsch
• Part: 0411-291-1405
• Type: Contact removal / extraction tool
• Contact size: 16 (14/16 GA)
• Not compatible with: Mil-Spec / Autosport connectors
