DTM06-3S

Deutsch DTM 3-Way Plug Connector – Grey Sealed Housing

The Deutsch DTM Series 3-way plug is a compact, lightweight sealed connector housing designed for motorsport signal circuits, sensor wiring, and fine-pitch harness applications where the larger DT Series is oversized. The DTM connector uses size 20 contacts and a smaller overall footprint, making it the preferred choice for ECU sensor inputs, data acquisition wiring, and tightly packaged harness runs in race and performance vehicles.

DTM Series Design Advantages

The DTM Series offers the same environmental sealing and positive contact retention as the DT Series but in a significantly smaller package. Sealed to IP67 when mated, the DTM housing provides robust protection for signal-level circuits in engine bays, cockpit looms, and underbody harness routing. Size 20 contacts are appropriate for 16–20 AWG signal and low-current wiring, keeping harness weight and bulk to a minimum in performance builds.

Typical Applications

• ECU sensor input branch connectors
• Data acquisition and logging system harness connectors
• Compact sensor connectors in tight engine bay and cockpit locations
• CAN bus and communication harness connectors
• Mazda RX-Series and turbocharged engine management sensor circuits
• Motorsport harness builds where size and weight are critical

Compatibility

Accepts Deutsch DTM size 20 contacts (solid and stamped). Compatible with WM-3S wedge locks and DTM dust cap accessories. Mates with DTM04-3P receptacle housing. Sold individually.
