AiM PDM 35-Way Connector Kit — Motorsport Wiring Connector Kit
The 68245 is a complete connector kit for 35-way connector for AiM PDM power distribution module harness interface on AiM Sports PDM units and compatible motorsport power distribution modules requiring a 35-way connector for primary harness connection. This kit contains the housing, terminal contacts, and any sealing or locking components needed to fabricate or repair a complete 35-way connector for AiM PDM power distribution module harness interface circuit connection, providing an OEM-compatible or application-specific interface that mates correctly with the target device.
Application Context
The AiM PDM provides programmable power distribution with overcurrent protection for motorsport vehicles, replacing conventional fuse boxes and relay boards with a single solid-state unit. The primary 35-way harness connector carries the PDM output circuit feeds, input power, and CAN bus communication circuits. A correctly fabricated harness connector at the PDM is essential for reliable power distribution throughout the race car electrical system.
Why Use Correct Application-Specific Connector Kits
When fabricating a race car harness or repairing a motorsport wiring loom, using the correct connector for each sensor, actuator, or ECU interface is essential for both reliability and serviceability. Non-matching connectors require modification or adapters that introduce additional connection points, increase harness complexity, and may produce a mechanically insecure fit that loosens under vibration. Purpose-specific connector kits provide the exact housing geometry, contact type, and locking mechanism designed for the target device, ensuring a vibration-resistant, sealed connection that will remain reliable through a racing season.
Kit Contents
Each connector kit includes the plug or receptacle housing, crimp contacts rated for the circuit wire gauge, and any wedge locks, seals, or secondary locking components included in the original connector design. All components needed to build the harness-side connector assembly are included.
Typical Build Applications
This connector is used for AiM PDM harness fabrication, motorsport power distribution module installation harness building, and primary PDM connector wiring for race car electrical system builds. It is a standard component in professional race car harness builds and motorsport vehicle wiring projects across Scandinavia, where correct application-specific connector specifications are a baseline requirement for reliable engine management, data acquisition, and power distribution system wiring.
Available from Arctic Performance Parts
Arctic Performance Parts stocks an extensive range of application-specific motorsport connector kits covering ECU, PDM, lambda sensor, wideband controller, and powersport platform interfaces commonly encountered in Scandinavian motorsport. Lead time is 1–2 weeks for quantities beyond current stock. Our team can assist in identifying the correct connector kit for your specific ECU or sensor application.
