Deutsch Autosport ASX — 6-Way Inline Socket (Female), Red Key (N)
The Deutsch Autosport ASX 6-Way Inline Socket (Female) — Red Key (N) — SKU: ASX102-06SN-HE is a genuine MIL-spec-grade miniature circular connector for compact, weight-sensitive motorsport sub-harness separable joins in professional race cars, rally, and high-performance builds across Norway, Sweden, and Denmark. This is the socket half of the mated pair — Pin (Male) must be ordered separately.
Shell and Circuit Count — ASX102, 6-Way
The ASX series retains the gold-plated contacts, aluminium alloy shell, and push-pull locking of the standard AS series in a smaller, lighter body. The ASX102 — miniature inline shell for free-hanging cable-mounted harness separation points. At 6 circuits, suited to 6-circuit sensor cluster, coil group, and actuator bundle separable joins. Typical applications: 6-wire sensor clusters, dual coil-on-plug sub-connectors, throttle body actuator bundles, and combined 6-channel signal and power sub-harness interfaces.
Red Key (N) — Mis-Mate Protection
Red N is the non-keyed (neutral) variant — mates with any counterpart of the same circuit count and shell size regardless of key colour. Correct for service tools, test jumpers, PDI connectors, and any interface where mating flexibility is preferred over strict mis-mate protection. Used by race teams across Norway, Sweden, and Denmark.
Inline Configuration — In-Harness Separable Join
Both halves sit within the harness run — neither is fixed to a panel or bulkhead. They float within the loom, held by sleeving or tie-wrap points. Standard for engine-to-chassis harness splits and removable subframe sub-harness joins. Used by motorsport wiring specialists across Norway, Sweden, and Denmark wherever a fixed panel location is not required.
Technical Specifications — ASX102-06SN-HE
- Series: Deutsch Autosport ASX (Miniature)
- Shell: ASX102 — miniature inline shell for free-hanging cable-mounted harness separation points
- Circuit count: 6-way
- Configuration: Inline (free-hanging inline)
- Contact type: Socket (Female)
- Key colour: Red (Key N)
- Shell material: Aluminium alloy, MIL-spec machined
- Contact plating: Gold over nickel
- Operating temperature: −65°C to +175°C
- Locking: Push-pull positive lock collar
- Contacts: Ordered separately — not included
- Mating half required: Pin (Male), same circuit count, shell, and key colour
