Deutsch Autosport ASDD 41-Way Plug — Pin (Male) — Blue Key (B)
The Deutsch Autosport ASDD 41-Way Plug Pin (Male) Connector with Blue (B) Keying Insert — SKU: ASDD612-41PB is a professional MIL-spec-grade motorsport connector configured as a free-hanging, cable-mounted plug half that mates with a fixed panel-mount or inline receptacle. Designed for primary ECU harness separable joins, PDM main connector interfaces, and high-circuit-count motorsport loom separation points, this connector delivers the vibration resistance, environmental sealing, and positive push-pull locking performance that professional race teams and harness builders throughout Norway, Sweden, and Denmark depend on for their most critical harness separable join points.
ASDD Plug Configuration — How It Differs from Inline and Flange
The plug configuration is a cable-mounted free connector half — it does not mount to a panel or chassis surface. The plug mates with a fixed inline or flange-mount receptacle half, creating a separable join where the plug side can be freely disconnected from the vehicle harness for removal.
Contact Type — Pin (Male)
This is the pin (pin) half of the 41-way ASDD pair. It mates with the corresponding socket half of the same circuit count and key colour. Both contact halves are required to form a complete mated connector pair. ASDD contacts are ordered separately — select the appropriate contact part number for your wire gauge.
Blue Key (B) — Mis-Mate Protection
The second keying position in the asdd system — the blue b insert ensures the second connector of the same circuit count on a harness cannot be cross-mated with the yellow a or any other keyed variant during installation or servicing. The blue keying insert physically prevents mating with any other ASDD 41-way connector of a different key — critical for harnesses where multiple same-size connectors are used in close proximity.
Technical Specifications
- Series: Deutsch Autosport ASDD
- Circuits: 41-way
- Configuration: Plug (free-hanging cable connector)
- Contact type: Pin (Male)
- Key colour: Blue (Key B)
- Shell material: Aluminium alloy
- Operating temperature: -65°C to +175°C
- Locking: Push-pull positive lock
