VERSAKRIMP 6 GA RING TERMINAL #10 BRAZED SEAM

Molex Versakrimp 6 GA Ring Terminal — #10 Brazed Seam Lug for Motorsport Primary Wiring

The Molex Versakrimp 6 GA Ring Terminal with #10 hole (19193-0209) is a heavy-duty brazed-seam crimp lug for motorsport and high-performance vehicle primary circuit terminations. At 13.3 mm² conductor cross-section with a continuous current capacity of approximately 75–95 amps, this terminal is suited to main battery distribution feeds, alternator output connections, and high-current earth straps. The brazed seam barrel construction provides a stronger, more reliable crimp joint than a simple rolled-seam barrel, maintaining electrical integrity under the vibration and thermal cycling of a race car environment.

Brazed Seam Construction

A brazed seam barrel is formed from copper that is rolled into a cylinder and then joined with a brazed filler material that closes the seam completely, creating a fully continuous cylindrical conductor. Under heavy crimp forming pressure at large wire gauges, a brazed seam barrel resists splitting — a failure mode seen with lower-quality terminals when crimping heavy conductors. The result is a tighter, more consistent crimp that reduces the risk of high-resistance joints in primary power circuits.

#10 Hole Size — M5 equivalent

#10 (M5) stud mount — suitable for earthing points, auxiliary fuse holder studs, and small terminal block connections. Selecting the correct hole size for the target stud is essential: an undersized hole cannot be installed, while an oversized hole leaves the terminal loose on the stud even when the nut is tight, creating micro-movement under vibration that accelerates contact surface oxidation.

6 GA — Typical Applications

This ring terminal is suited to main battery distribution feeds, alternator output connections, and high-current earth straps. At this cable gauge, the terminal is part of the primary power circuit — the highest-current section of the vehicle’s electrical system — making a correctly specified and installed terminal critically important for both performance and safety.

Available from Arctic Performance Parts

Arctic Performance Parts stocks Molex Versakrimp heavy-duty ring terminals across multiple gauges (6 GA through 3/0 GA) and all common hole sizes to support professional motorsport builds and fabrication workshops across Scandinavia. Lead time is 1–2 weeks for quantities beyond current stock.
