TXL 10 GA YELLOW

TXL 10 GA YELLOW Automotive Wire — Motorsport Harness Cable

TXL 10 GA YELLOW wire from Arctic Performance Parts is a cross-linked polyethylene (XLPE) insulated automotive conductor built to SAE J1128 TXL specification. With a conductor cross-section of 5.26 mm² and a continuous current rating of approximately 40–55 amps (depending on installation environment and bundling), this wire is engineered for the demanding thermal and chemical environment of a race car or high-performance road vehicle. The yellow insulation colour provides clear, consistent circuit identification throughout a completed wiring harness.

What Is TXL Wire?

TXL (extra-thin wall cross-linked polyethylene) wire is the automotive wire standard specified by SAE J1128 for high-temperature, space-critical applications. The cross-linked insulation provides a continuous temperature rating of 125°C — significantly higher than the 80°C or 105°C ratings of standard PVC or GPT automotive wire — while maintaining a thinner overall jacket that reduces harness diameter and weight. TXL wire resists automotive fluids including fuel, oil, brake fluid, and coolant, and retains flexibility down to −40°C, making it suitable for under-bonnet, firewall, and chassis wiring in all climates. 10 GA TXL wire bridges the gap between the very heavy 8 GA and the mid-range 12 GA, providing a practical conductor for circuits drawing 40–55 amps continuously where full 8 GA bulk is unnecessary.

Yellow Insulation — Circuit Colour Coding

The yellow TXL wire variant is commonly used for auxiliary power and switched accessory circuits in professionally built motorsport harnesses. Yellow wiring is a widely recognised colour for accessory and auxiliary circuits in automotive harness standards, and is commonly used for switched feeds to ancillary devices and warning systems. Consistent colour coding discipline — assigning the same colour to the same circuit type across every vehicle — is a professional harness building practice that dramatically reduces diagnostic time during fault-finding and repair at the track.

Primary Motorsport Applications — 10 GA

TXL 10 GA wire is well suited to alternator charge lines, fan motor feeds, and sub-main power distribution. Secondary applications include electric water pump circuits, twin-fan wiring, and high-draw accessory feeds. Its conductor cross-section makes it a practical choice for any circuit where 10 gauge is the correct sizing based on the circuit’s current draw, length, and acceptable voltage drop budget.

TXL vs Tefzel (Mil-Spec) Wire — Choosing the Right Product

TXL wire is the correct choice for the majority of motorsport harness circuits where cost, availability, and flexibility are balanced priorities. Tefzel (M22759/32 ETFE) wire is preferred for critical signal circuits, circuits exposed to extreme heat sources (near turbocharger housings or exhaust manifolds), or applications where the lightest possible weight is essential. For chassis wiring, power distribution, and general motorsport harness builds, TXL wire in the appropriate gauge and colour provides excellent long-term reliability at an accessible price point.

Supplied by Arctic Performance Parts

Arctic Performance Parts stocks TXL wire across all key gauges and a comprehensive colour range to support professional harness builders, motorsport workshops, and performance enthusiasts building and repairing wiring looms. Quantities beyond current stock are available on a 1–2 week lead time from our specialist wiring suppliers. Order by the metre or in reel quantities to suit your build requirements.
