STEP DOWN BUTT CONN 12-10 TO 16-14

Step-Down Butt Splice Connector — 12–10 AWG to 16–14 AWG for Motorsport Harness Wire Gauge Transitions

The 19215-0023 is a step-down (reducer) butt splice connector for joining 12–10 AWG to 16–14 AWG wire in motorsport and automotive wiring harnesses. Step-down splices accept two different wire gauges — one in each end of the barrel — allowing direct crimp-joined transitions between a heavier and a lighter conductor at a single splice point without requiring an intermediate terminal block or a junction of two same-gauge splices. This splice is suited to joining a high-current feed wire to a branch circuit of lighter gauge — for example, connecting a 10 AWG primary distribution feed to a 14 AWG secondary circuit, or splicing a 12 AWG power supply to a 16 AWG switched output.

Why Step-Down Splices Are Used in Motorsport Harnesses

Motorsport wiring harnesses commonly include circuits where the wire gauge changes mid-route — for example, where a primary power feed of 10 AWG steps down to individual branch circuits of 14–16 AWG at a distribution point, or where a relay output at 14 AWG steps down to signal-level wiring at 20–22 AWG at a control circuit branch point. Running the heavy-gauge wire all the way to its end device wastes weight and material; stepping down to the appropriate gauge for each circuit segment minimises harness weight while ensuring correct current-carrying capacity in each section. The step-down butt splice is the crimp component that makes this gauge transition at a single junction point, maintaining the harness integrity without requiring a bulky junction block.

Gauge Compatibility — 12–10 AWG to 16–14 AWG

The 19215-0023 accepts 12–10 AWG in one barrel end and 16–14 AWG in the other. The barrel diameters at each end are independently sized for the respective gauge, ensuring a correctly formed crimp on both conductors. Using a same-gauge splice across a gauge step results in an incorrectly formed crimp on the smaller conductor — the barrel does not deform correctly around a significantly undersized wire, producing a weak joint. Always use the correct step-down splice part number for the specific gauge combination being joined.

Available from Arctic Performance Parts

Arctic Performance Parts stocks Molex Versakrimp step-down butt splices in the standard motorsport gauge combinations to support professional harness construction across Norway, Sweden, and Denmark. Lead time 1–2 weeks for quantities beyond current stock.
