METRI-PAK 630 SEAL BLUE

Delphi Metri-Pak 630 Seal Blue – Individual Wire Seal for Large-Gauge Metri-Pak Connectors

The Delphi Metri-Pak 630 Seal in Blue (15324996) is a colour-coded individual wire seal designed for the Metri-Pak 630 connector series – the large-gauge variant of the Delphi Metri-Pak sealed connector family. The blue colour identifies the specific wire diameter range this seal is designed for, allowing harness builders across Norway, Sweden, and Denmark to quickly and accurately select the correct seal for each circuit in a mixed-gauge harness assembly.

Metri-Pak 630 – Large-Format Sealed Connector System

The Delphi Metri-Pak 630 series is the large-gauge sealed connector system in the Metri-Pak range, designed for heavier wire gauges and higher-current circuits than the 150 or 280 series. The 630 designation relates to the larger contact cavity size required to accommodate thick-wall wire insulation and large-gauge copper conductors. Applications include main power distribution connectors, high-current relay block interfaces, and other heavy-gauge circuit terminations in motorsport harness builds.

Blue Seal – Gauge Identification

Colour coding is used across the Delphi Metri-Pak seal range to help builders match seals to wire gauges without measuring each time. Blue identifies the specific OD range for this seal within the MP630 system. Always verify the wire insulation OD against the seal’s specified range before assembly to ensure a proper environmental seal.

Specifications

• Series: Delphi Metri-Pak 630
• Type: Individual wire seal
• Colour: Blue (wire gauge identification)
• Application: Environmental sealing for large-gauge circuits in MP630 connector assemblies
