M22759/32-20-02 BLACK/RED BTF STRIPE

M22759/32-20-02 Black/Red BTF Stripe – 20 AWG Silicone MIL-SPEC Wire for Fine-Gauge High-Temperature Wiring

The M22759/32-20-02 is a 20 AWG MIL-SPEC wire with a black base and red BTF stripe, silicone insulation, and a silver-plated copper conductor. Built to the M22759/32 military specification, it provides fine gauge performance and extended temperature capability for professional harness fabrication in motorsport, aerospace, and high-performance vehicle applications. Supplied pre-spooled.

Black/Red BTF Stripe Identification

The black base with red BTF stripe (-02) provides a high-contrast warm-tone identifier within the black-base family at 20 AWG. Red against black is immediately visible and provides stronger contrast than the closely toned black/brown (-01) — the saturated red stripe stands out clearly against the black base. This wire completes the second black-base variant in the three-wire group (-01, -02, -03) that rounds out the lower end of the black-base 20 AWG silicone range not covered in the earlier batch.

Key Specifications

• Specification: MIL-SPEC M22759/32
• Gauge: 20 AWG
• Insulation: Silicone
• Conductor: Silver-plated copper
• Colour: Black base with Red BTF stripe
• Format: Pre-spooled (PRSP)
• Temperature rating: -65°C to +200°C continuous

Applications

Used in motorsport harness construction, aerospace wiring, and high-performance vehicle electrical builds at 20 AWG. Compatible with standard motorsport connector systems and professional crimp tooling.
