Deutsch HD30 Series — 9-Way Receptacle, Shell Size 24, Socket Contacts, N Key
The Deutsch HD30 9-Way Receptacle — Shell Size 24, Socket Contacts, N Key — SKU: HD34-24-9SN is a fixed-side chassis or panel receptacle in the Deutsch HD30 series, configured with socket (female) contacts in the fixed body — a reversed-gender arrangement compared to the standard HD30 convention. With 9 circuits in a shell size 24 body, this receptacle delivers outstanding mechanical robustness and large-gauge contact accommodation within its 9-position insert, for specific applications where the fixed connector must carry socket contacts.
Socket Contacts in the Fixed Receptacle — Reversed Gender Convention
Standard HD30 practice places pin contacts in the fixed receptacle, with socket contacts in the cable-mount plug. The HD34-24-9SN reverses this by placing socket (female) contacts in the fixed body — used when the application requires this gender assignment either to mate with a specific component-mounted plug carrying pin contacts, or when the circuit design specifies socket contacts in the chassis-fixed position for a defined system reason. When ordering, confirm the contact gender of the mating plug to ensure the complete connector pair is correctly specified.
9 Circuits in Shell Size 24 — Maximum Per-Circuit Robustness
Nine circuits spread across the full shell size 24 insert gives each circuit position the most generous contact spacing available in the HD30 system — accommodating the largest available contact gauges with maximum surrounding shell material. This configuration is selected for very high-current circuits, safety-critical connections, and applications where the connector must withstand extreme mechanical loads at the connection point, such as main battery distribution interfaces and high-power motor drive connections.
Technical Specifications — SKU HD34-24-9SN
- Series: Deutsch HD30
- Configuration: Receptacle (HD34 — fixed/chassis mount)
- Shell size: 24
- Circuit count: 9-way
- Contact type: Socket (Female)
- Key: N (Neutral)
- Shell material: Aluminium alloy
- Sealing: Environmental, HD30-rated
- Contacts: Ordered separately
