GT150 MALE TERM SEALED 22-20

Delphi GT150 Male Terminal Sealed 22-20 AWG – Fine-Gauge Male Contact for GT150 Connector Assemblies

The Delphi GT150 Male Terminal Sealed for 22-20 AWG wire (15326268) is a sealed male crimp contact designed for the Delphi GT 150 connector series in the fine-gauge wire range. Used on the plug (male housing) side of a GT150 connector assembly, this terminal provides the male contact half of sensor, signal, and low-current circuit connections in motorsport and performance vehicle harnesses across Norway, Sweden, and Denmark.

Male vs Female Terminal Selection in GT150 Assemblies

In a GT150 connector assembly, the male terminal populates the plug (male housing) side, while the female terminal populates the receptacle (female housing) side. The plug and receptacle housings are distinct components with different locking geometries. Always select male or female terminals to match the housing side being assembled, and verify gauge range compatibility for the wire being used before ordering.

22-20 AWG Fine-Gauge Signal Circuit Applications

• ECU sensor input circuits (coolant temp, IAT, MAP, TPS)
• Wideband lambda sensor signal and reference circuits
• CAN bus high and low circuit signal wiring
• Knock sensor signal circuits
• Data acquisition system analogue and digital input connections

Specifications

• Part: 15326268
• Series: Delphi GT 150
• Terminal type: Male sealed crimp
• Wire gauge: 22–20 AWG
