22 AWG Tefzel Twisted Pair — Coloured Conductors Stripe two twists per inch (2 TPI) for Motorsport Differential Signal Circuits
The M22759/16-18-5/95 is an 18 AWG Tefzel (ETFE) twisted pair in coloured conductors stripe colour combination, twisted at two twists per inch (2 TPI). This striped twisted pair format uses one solid-colour conductor paired with a matching white-stripe conductor of the same base colour — for example, a solid brown conductor paired with a brown-and-white-stripe conductor. This colour convention provides clear polarity identification within the pair: the solid conductor is conventionally the positive or signal lead, and the striped conductor is the return or reference lead. This cable is suited to ECU differential sensor inputs, CAN bus pairs, data acquisition twisted pair circuits, and general motorsport signal pair applications.
Striped Twisted Pair — Polarity Convention
The stripe-and-solid pair colour convention is used throughout aerospace and professional motorsport harness practice for differential circuit pairs where the two conductors must be clearly identified as positive and negative (or signal and return) throughout the harness. Using a striped conductor alongside a solid conductor of the same base colour means both conductors share the circuit’s colour code, while the stripe distinguishes the return from the signal. This is particularly important for thermocouple pairs, differential sensor circuits, and any circuit where reversal of the two conductors would produce an incorrect measurement or circuit damage.
two twists per inch (2 TPI) — Twist Rate
The twist rate determines the degree of common-mode noise rejection provided by the twisted pair. A tighter twist (more twists per inch) provides better noise rejection by ensuring both conductors in the pair experience nearly identical electromagnetic environments throughout their length — any noise induced on the pair affects both conductors equally and cancels at the differential receiver. Two TPI is used for circuits in moderate EMI environments; for circuits in high-EMI areas (near ignition wiring or high-current switching), shielded cable should be considered in addition to or instead of twisted pair.
Available from Arctic Performance Parts
Arctic Performance Parts stocks Tefzel twisted pair cables in a range of AWG sizes, twist rates, and colour combinations to support professional motorsport harness builders across Norway, Sweden, and Denmark. Lead time 1–2 weeks for quantities beyond current stock.
