Garrett Performance Intercoolers And Intercooler Cores Work Together With The Turbocharger As Part Of The Total Induction System. When Air Is Compressed In The Turbocharger It Yields A Lot Of Heat. The Job Of The Intercooler Is To Remove Heat From The Charge Air Making It More Dense. A Denser Charge Equals More Air And Fuel To The Engine And That Translates To More Horsepower Potential.
Key Features
- High Efficiency Bar And Plate Construction
- Vacuum Brazed Manufacturing For Durability
- Advanced Offset Fin Design For Greater Heat Transfer Effictiveness
- Air-To-Air Horizontal Flow Design
| Product Specifications | Details |
|---|---|
| Intercooler Cores Modell | Air/Air |
| Flow Direction | Horizontal Flow |
| Engine HP | 740 |
| Engine HP Range | 700-800 |
| Length | Hot Flow (mm) | 229.00 |
| Length | Hot Flow (in) | 9.00 |
| Height | No Flow (mm) | 560.00 |
| Height | No Flow (in) | 22.10 |
| Width | Cold Flow (mm) | 102.00 |
| Width | Cold Flow (in) | 4.00 |
