Garrett GTX5020R GEN II Super Core No Turbine Housing 1075-2050hp – 76mm

Description

GTX And GTX Gen II Series Turbochargers Are An Evolution Of The GT Series Product Line. The Original Architecture Of The GT Series Turbos Remains However Many Design And Performance Features Have Been Introduced Over Time. Ceramic Dual Ball Bearings And Forged Fully-Machined Compressor Wheels With GTX And GTX Gen II Aerodynamics Provide A Larger Horsepower Range And Maximize Boost Response.

Key Features

• Gen II Compressor Wheel Aerodynamics
• 88MM Compressor Inducer | 120MM Compressor Exducer
• 99MM Turbine Inducer | 91MM Turbine Exducer
• 9% Increased Compressor Flow
• Larger .88 A/R Compressor Housing Volute
• GTX5020R Features A 120MM Comp Exducer ( + 2 MM) And Has 30% Lower Inertia Compared To GTX5018R
• Supercore And Turbine Housing Sold Separately
• Compatible With GT And GTX Turbine Housings
• 88MM Supercore 851285-5020S

Maximum Allowable Turbocharger Speed

93KRPM. The Use Of This Product Above Max Turbocharger Speed Is At The Owner’s Risk, And Can Result In Damage And Premature Failure. To Protect The Turbocharger From Overspeed When Operating, A Speed Sensor Can Be Installed Into The Compressor Housing To Monitor Shaft Speed. Sensors Sold Separately.

Performance Results Of This Product Are Highly Dependent Upon Your Vehicle’s Modifications And Tuning/Calibration. The Horsepower Numbers Represented Above Are Calculated Based Strictly On Choke Flow Of The Compressor Map (Total Turbo Capability), Which Represents The Potential Flywheel Horsepower.
