Deutsch Industrial Stamped Contacts / Terminals

Description

Deutsch Industrial Stamped Contacts / Terminals Deutsch offers two styles of contacts, stamped & formed and solid. Both contact types use a crimp style termination, eliminating the need for solder. All Deutsch Industrial terminals protect the split socket tines. The only variations in the Deutsch Common Contact System are those dictated by wire gauge and contact style. Below you find an assortment of Deutsch industrial series stamped contacts / terminals, stocked in both Nickel and gold plated variants where available. If you would like to dig deeper into the Deutsch Common Contact System please Click Here for specifically selected pages from the Deutsch Industrial catalog. Series Contact Size Wire Range AWG Max Amps* OE Crimp Tool Econo Crimp Tool** DT 16 20-14 13 DTT-16-00 18600 DTM 20 22-16 7.5 DTT-20-00 18600 DTP / DTHD 12 14-12 25 DTT-12-00 18610 DTP / DTHD 12 10 25 DTT-12-01 SP2084 * Max amperage rating is per contact. ** All Econo crimp tool recomendations are generic use crimp tools and will crimp many different types of open barrel or stamped and formed contacts
