Deutsch Autosport ASX (Miniature) Series — 3-Way Flange Pin (Male)
The Deutsch Autosport ASX 3-Way Flange Pin (Male) — Green Key (D) — SKU: ASX002-03PD-HE is a genuine MIL-spec-grade panel-mounted connector for 3-circuit sensor, actuator, and switch sub-harness separable joins in professional race cars, rally, hillclimb, and high-performance builds across Norway, Sweden, and Denmark. This is the pin half of the mated pair — Socket (Female) must be ordered separately to complete the join.
Shell and Circuit Count — ASX002, 3-Way
The ASX series is a miniaturised circular connector built to MIL-spec standards for space-constrained and weight-sensitive motorsport wiring applications. It retains the same gold-plated contacts, aluminium alloy shell, and positive push-pull locking as the standard AS series, in a smaller circular body suited to compact sub-harness builds. The ASX002 is the ASX002 — flange-mount miniature shell for panel and bulkhead installations. At 3 circuits, this connector is suited to 3-circuit sensor, actuator, and switch sub-harness separable joins. Common applications include 3-wire sensor assemblies (MAP, TPS, CLT, IAT), individual coil-on-plug sub-connectors, 3-wire actuator feeds, and small auxiliary circuit groupings.
Green Key (D) — Mis-Mate Protection
Green D is the fourth key colour — reserved for the fourth 3-circuit ASX flange bundle at a separation point carrying four parallel pairs. Combined with Yellow A, Blue B, and Orange C, Green D completes a fully locked four-key arrangement where no pair can be accidentally mated to another. Four-key configurations represent the maximum mis-mate protection available in the Deutsch Autosport system. They are used only on the most complex professional race car loom builds across Norway, Sweden, and Denmark.
Flange Mount — Panel and Bulkhead Installation
The flange connector mounts through a panel cutout via its integral aluminium flange — fixing one half permanently to the chassis, firewall, or bulkhead. The mating cable-mounted half plugs directly into the fixed half, creating a precise, repeatable separable interface at the panel itself. This is the standard for primary chassis separation points, engine bay to cabin firewall joins, and fixed bulkhead interfaces. Flange connectors are the professional choice for motorsport workshops across Norway, Sweden, and Denmark.
Technical Specifications — ASX002-03PD-HE
- Series: Deutsch Autosport ASX
- Shell: ASX002
- Circuit count: 3-way
- Configuration: Flange (flange-mount (panel/bulkhead))
- Contact type: Pin (Male)
- Key colour: Green (Key D)
- Shell material: Aluminium alloy, MIL-spec machined
- Contact plating: Gold over nickel
- Operating temperature: −65°C to +175°C
- Locking: Push-pull positive lock collar
- Contacts: Ordered separately — not included
- Mating half required: Socket (Female), same circuit count, shell, and key colour
