Deutsch Autosport ASL (Low-Profile) Series — 5-Way Flange Socket (Female)
The Deutsch Autosport ASL 5-Way Flange Socket (Female) — Green Key (D) — SKU: ASL006-05SD-HE is a genuine MIL-spec-grade panel-mounted connector for 5-circuit sensor cluster and actuator bundle separable joins in professional race cars, rally, hillclimb, and high-performance builds across Norway, Sweden, and Denmark. This is the socket half of the mated pair — Pin (Male) must be ordered separately to complete the join.
Shell and Circuit Count — ASL006, 5-Way
The ASL series is a reduced axial-depth circular connector designed for installations where radial clearance behind a panel, bulkhead, or within a tight harness bundle prevents use of a standard-depth AS shell. It delivers the same gold-plated contacts, aluminium alloy shell, and push-pull locking in a shallower body. The ASL006 is the ASL006 — low-profile flange-mount shell for depth-constrained panel installations. At 5 circuits, this connector is suited to 5-circuit sensor cluster and actuator bundle separable joins. Common applications include 5-wire sensor clusters, combined power/ground/signal interfaces, 5-channel switch pack sub-connectors, and mixed signal and power actuator bundles.
Green Key (D) — Mis-Mate Protection
Green D is the fourth key colour — reserved for the fourth 5-circuit ASL flange bundle at a separation point carrying four parallel pairs. Combined with Yellow A, Blue B, and Orange C, Green D completes a fully locked four-key arrangement where no pair can be accidentally mated to another. Four-key configurations represent the maximum mis-mate protection available in the Deutsch Autosport system. They are used only on the most complex professional race car loom builds across Norway, Sweden, and Denmark.
Flange Mount — Panel and Bulkhead Installation
The flange connector mounts through a panel cutout via its integral aluminium flange — fixing one half permanently to the chassis, firewall, or bulkhead. The mating cable-mounted half plugs directly into the fixed half, creating a precise, repeatable separable interface at the panel itself. This is the standard for primary chassis separation points, engine bay to cabin firewall joins, and fixed bulkhead interfaces. Flange connectors are the professional choice for motorsport workshops across Norway, Sweden, and Denmark.
Technical Specifications — ASL006-05SD-HE
- Series: Deutsch Autosport ASL
- Shell: ASL006
- Circuit count: 5-way
- Configuration: Flange (flange-mount (panel/bulkhead))
- Contact type: Socket (Female)
- Key colour: Green (Key D)
- Shell material: Aluminium alloy, MIL-spec machined
- Contact plating: Gold over nickel
- Operating temperature: −65°C to +175°C
- Locking: Push-pull positive lock collar
- Contacts: Ordered separately — not included
- Mating half required: Pin (Male), same circuit count, shell, and key colour
