Deutsch Autosport ASDD 64-Way Flange — Pin (Male) — Yellow Key (A)
The Deutsch Autosport ASDD 64-Way Flange Pin (Male) Connector with Yellow (A) Keying Insert — SKU: ASDD014-64PA is a professional MIL-spec-grade motorsport connector configured as a panel or bulkhead-mounted flange connector that bolts directly to a chassis panel, firewall, or mounting plate — providing a fixed, chassis-anchored connector point. Designed for high-density ECU main harness connectors, full PDM wiring system interfaces, and complex race car loom separable joins requiring maximum circuit count in a single mid-size shell, this connector delivers the vibration resistance, environmental sealing, and positive push-pull locking performance that professional race teams and harness builders throughout Norway, Sweden, and Denmark depend on for their most critical harness separable join points.
ASDD Flange Configuration — How It Differs from Inline and Flange
The flange configuration mounts permanently to a panel, bulkhead, or chassis member using the integrated mounting flange — creating a fixed, chassis-anchored connector point. The cable harness plugs into the flange-mount half from the wiring loom side, making the flange connector the standard choice for firewall bulkhead connectors, chassis separation points, and any location where one connector half must be permanently fixed to the vehicle structure.
Contact Type — Pin (Male)
This is the pin (pin) half of the 64-way ASDD pair. It mates with the corresponding socket half of the same circuit count and key colour. Both contact halves are required to form a complete mated connector pair. ASDD contacts are ordered separately — select the appropriate contact part number for your wire gauge.
Yellow Key (A) — Mis-Mate Protection
The first standard keying position — yellow a is the most widely specified starting key when multiple same-circuit-count asdd connectors appear on a single harness, ensuring each connector pair can only mate with its correct counterpart. The yellow keying insert physically prevents mating with any other ASDD 64-way connector of a different key — critical for harnesses where multiple same-size connectors are used in close proximity.
Technical Specifications
- Series: Deutsch Autosport ASDD
- Circuits: 64-way
- Configuration: Flange (panel-mounted flange connector)
- Contact type: Pin (Male)
- Key colour: Yellow (Key A)
- Shell material: Aluminium alloy
- Operating temperature: -65°C to +175°C
- Locking: Push-pull positive lock
