Deutsch Autosport ASDD 11-Way Plug — Pin (Male) — Green Key (D)
The Deutsch Autosport ASDD 11-Way Plug Pin (Male) Connector with Green (D) Keying Insert — SKU: ASDD608-11PD is a professional MIL-spec-grade motorsport connector configured as a free-hanging, cable-mounted plug half that mates with a fixed panel-mount or inline receptacle. Designed for small ECU auxiliary connector interfaces, compact sensor group harness joins, and secondary loom separable points, this connector delivers the vibration resistance, environmental sealing, and positive push-pull locking performance that professional race teams and harness builders throughout Norway, Sweden, and Denmark depend on for their most critical harness separable join points.
ASDD Plug Configuration — How It Differs from Inline and Flange
The plug configuration is a cable-mounted free connector half — it does not mount to a panel or chassis surface. The plug mates with a fixed inline or flange-mount receptacle half, creating a separable join where the plug side can be freely disconnected from the vehicle harness for removal.
Contact Type — Pin (Male)
This is the pin (pin) half of the 11-way ASDD pair. It mates with the corresponding socket half of the same circuit count and key colour. Both contact halves are required to form a complete mated connector pair. ASDD contacts are ordered separately — select the appropriate contact part number for your wire gauge.
Green Key (D) — Mis-Mate Protection
The fourth keying position — the green d insert is used on harnesses requiring four uniquely-keyed connectors of the same circuit count, typically found in full race car loom builds with multiple ecu and pdm separable joins. The green keying insert physically prevents mating with any other ASDD 11-way connector of a different key — critical for harnesses where multiple same-size connectors are used in close proximity.
Technical Specifications
- Series: Deutsch Autosport ASDD
- Circuits: 11-way
- Configuration: Plug (free-hanging cable connector)
- Contact type: Pin (Male)
- Key colour: Green (Key D)
- Shell material: Aluminium alloy
- Operating temperature: -65°C to +175°C
- Locking: Push-pull positive lock
