AS,4 WAY,PLG,SKT,A KEY,YELLOW

Deutsch Autosport AS 4-Way Plug — Socket (Female) — Yellow Key (A)

The Deutsch Autosport AS 4-Way Plug Socket (Female) Connector with Yellow (A) Keying Insert — SKU: AS612-04PA is a professional MIL-spec-grade Deutsch Autosport AS series connector for compact 4-wire sensor, switch, and actuator harness separable joins in race cars and high-performance vehicles across Norway, Sweden, and Denmark. Configured as a free, cable-mounted plug half that mates with a fixed flange or inline receptacle — the movable, harness-side component that disconnects for component removal, harness separation, and servicing.

Deutsch Autosport AS 4-Way — 4-circuit Circuit Configuration

The Deutsch Autosport AS series is the professional standard circular connector format for motorsport wiring — aluminium alloy shell, gold-plated contacts, positive push-pull locking, and full MIL-spec environmental sealing for race-condition reliability. The 4-circuit configuration is used for compact 4-wire sensor assemblies, individual actuator connectors, and auxiliary circuit separable points where minimal size is a priority in professional motorsport builds throughout Scandinavia. Compact 4-circuit format — prioritising minimal connector size and weight for sub-harness joins with a defined low circuit count.

Socket (Female) — 4-Circuit Contact Array

This is the socket half of the 4-way AS plug pair. Four gold-plated socket contacts receive four incoming pin contacts — the receptacle half completing each of the four circuits when the connector is mated. The corresponding pin half of the same circuit count and key colour completes the mated pair — both halves are required. AS contacts are ordered separately; select the correct contact part number for your wire gauge and current requirements.

Yellow Key (A) — Keying Position and Mis-Mate Prevention

Yellow A is the first key assigned in any Deutsch AS multi-connector keying plan — the default primary key that every harness builder reaches for when a harness includes multiple 4-circuit AS connectors at the same separation point. The Yellow A physical key tab on this plug half ensures it will only accept a matching Yellow A-keyed mating half — preventing cross-mating with any Blue B, Orange C, Green D, or Red N keyed half of the same circuit count. On a harness with two or more 4-circuit AS plug connectors at the same separation point, Yellow A identifies the primary pair — typically the most frequently accessed connector or the one carrying the most critical circuits. Professional harness builders across Norway, Sweden, and Denmark standardise on Yellow A as the primary key assignment for consistency across multiple builds and to simplify harness identification for mechanics and engineers at race events.

Plug Configuration — The Movable Cable-Mounted Connector Half

The AS plug is the free, cable-mounted half of the connector pair — it does not mount to a panel or chassis surface. The plug travels with the removable component or sub-harness and mates into a fixed receptacle (flange-mounted or inline) to complete the electrical circuit when the assembly is connected. This makes the plug the correct specification for engine-side harness connectors that must be disconnected for engine removal, dashboard harness sub-connectors that follow a removable dashboard assembly, removable subframe harness joins, and any other separable point where one connector half must be freely movable with a removable vehicle component.

The 4-circuit AS plug is used for compact 4-wire sensor, switch, and actuator harness separable joins across race cars and performance vehicles in Norway, Sweden, and Denmark. The plug’s free, unmounted format allows the harness builder to route the cable bundle freely from the removable component to the mating point without any chassis mounting constraint — then mate the plug directly into the fixed receptacle when the component is installed. The push-pull positive locking mechanism provides secure, vibration-resistant engagement that holds through race conditions while allowing intentional disconnection at every service interval.

Technical Specifications

• Series: Deutsch Autosport AS
• Circuits: 4-way
• Configuration: Plug
• Contact type: Socket (Female)
• Key colour: Yellow (Key A)
• Shell material: Aluminium alloy
• Operating temperature: -65°C to +175°C
• Locking: Push-pull positive lock
• Typical application: Primary connector — first key assigned when two or more same-circuit-count as connectors share a harness
