Deutsch Autosport AS016 — 26-Way Flange Pin (Male) — Blue Key (B)
The Deutsch Autosport 26-Way Flange Pin (Male) Connector — Blue Key (B) — SKU: AS016-26PB is a genuine MIL-spec-grade Deutsch Autosport AS series panel-mounted connector built for 26-circuit high-density harness separation points on full race car looms in professional race cars, hillclimb, rally, and high-performance builds across Norway, Sweden, and Denmark. Configured as a flange-mount (panel/bulkhead) separable join, this connector is fixed to a chassis panel, firewall, or bulkhead surface via its integral mounting flange — delivering a clean, reliable, mechanically keyed separable interface at the harness separation point.
AS016 Shell — Series Architecture and Circuit Density
The AS016 is a medium circular flange-mount shell spanning circuit counts from 8 to 55 ways — covering everything from auxiliary sub-harness bulkhead interfaces to primary vehicle loom bulkhead separation points on full professional race car builds. The AS016 provides MIL-spec aluminium alloy shell construction, gold-plated contacts, and positive push-pull locking in a panel-mountable body suited to a wide range of circuit densities. The 26-circuit configuration in the AS016 shell is suited to 26-circuit high-density harness separation points on full race car looms. Typical applications at this circuit count include full ECU harness separation points, PDM main harness sub-connector joins, high-density combined signal and power distribution separation points, and engine-to-chassis primary loom joints. The 26-way flange is a very high circuit count used at primary harness separation points where maximum circuit consolidation is required in the AS016 shell.
Pin (Male) — 26-Circuit Contact Array
This listing supplies the pin half of the 26-way AS flange connector pair — gold-plated pin contacts 26 in total — carrying each circuit across the flange-mount (panel/bulkhead) separation point. To form a complete functional connector pair, the matching Socket (Female) half of the same circuit count, shell size, and key colour must be ordered separately; both halves are required to create a mated, functional separable join. AS series contacts are ordered independently of the connector shells — select the correct contact part number for your wire gauge, current rating, and preferred termination method.
Blue Key (B) — Keying Position and Mis-Mate Protection
Blue B is the second key assignment at a separation point that carries two parallel 26-circuit AS flange bundles. Once Yellow A has been allocated to the primary bundle, Blue B identifies the second — physically preventing a Blue B half from mating with a Yellow A, Orange C, or Green D counterpart. This mis-mate protection holds regardless of ambient conditions, time pressure, or the number of connectors in the vicinity. Blue B is most commonly encountered alongside Yellow A in two-bundle loom splits where two parallel 26-circuit groups must cross the same separation point. In Norwegian, Swedish, and Danish race car loom builds requiring two parallel 26-circuit AS flange joins at the same separation point, Yellow A and Blue B form the standard two-key pairing used by professional wiring shops and harness builders throughout Scandinavia.
Flange Configuration — Panel and Bulkhead Mounting
The AS flange connector mounts through a panel cutout using its integral aluminium mounting flange — fixing one half of the connector pair permanently to the chassis, firewall, or bulkhead surface. The mating free half (the cable-mounted opposite half) plugs directly into the panel-mounted half, creating a secure separable interface at the bulkhead itself. This configuration is used wherever the harness must separate cleanly at a fixed chassis point — engine bay to cabin firewall, removable subframe to chassis, fuel cell bay to main loom, or any other fixed panel location where one side of the harness needs a permanent, precision-located connection point. Flange connectors are the professional standard for primary chassis separation points in full race car loom builds. Flange-mount AS connectors are the standard choice for primary chassis and bulkhead separation points on race cars and high-performance vehicles built and maintained by loom specialists and motorsport workshops across Norway, Sweden, and Denmark.
Technical Specifications — AS016-26PB
- Series: Deutsch Autosport AS
- Shell size: AS016
- Circuit count: 26-way
- Configuration: Flange (flange-mount (panel/bulkhead))
- Contact type: Pin (Male)
- Key colour: Blue (Key B)
- Shell material: Aluminium alloy, MIL-spec machined
- Contact plating: Gold over nickel
- Operating temperature: −65°C to +175°C
- Locking mechanism: Push-pull positive lock collar
- Contacts: Ordered separately — not included
- Mating half required: Socket (Female), same circuit count, shell size, and key colour
