AS,16 WAY,INLINE,PIN,D KEY,GREEN

Deutsch Autosport AS 16-Way Inline — Pin (Male) — Green Key (D)

The Deutsch Autosport AS 16-Way Inline Pin (Male) Connector with Green (D) Keying Insert — SKU: AS120-16PD is a professional MIL-spec-grade motorsport connector for medium-complexity ECU sub-harness connectors, auxiliary PDM circuit joins, and sensor cluster harness separation points in race cars and performance vehicles across Norway, Sweden, and Denmark. This pin half is the active contact side — the gold-plated pin terminals mate with the corresponding socket (socket) half, transferring all 16 circuits across the inline separable join when the connector is locked. Configured as an inline connector — in-line harness separable join — both halves are free, cable-mounted connectors within the wire run.

Deutsch Autosport AS — 16-circuit Inline Connector

The Deutsch AS series is the standard Autosport circular connector format for professional motorsport — providing the 16-circuit capacity required for this application in a robust aluminium alloy shell with push-pull positive locking, gold-plated contacts, and full MIL-spec environmental sealing for race-condition reliability. Provides a practical balance between circuit density and connector size — used for ecu sub-loom joins, pdm auxiliary circuit interfaces, and sensor harness separation points where 13 circuits are insufficient but a larger 21 or 23-way shell would be unnecessarily bulky. The 16-way AS inline is particularly well suited for ECU sensor harness sub-loom separable joins, PDM auxiliary output interfaces, and dash/chassis harness splits in mid-complexity race car electrical systems.

Green Key (D) — The fourth keying position in the deutsch as system

As the fourth keying position in the Deutsch AS system, the Green D key completes the four-position keying system — used when four 16-way AS inline connectors are required at the same separation point on a complex race car harness. Green D is the fourth key assignment in a multi-connector harness. The availability of four colour-coded keying positions (Yellow A through Green D) means that up to four identical-size AS connectors can be used on the same harness without any risk of mis-mating — covering virtually all professional motorsport harness separation point requirements. With all four key colours assigned (Yellow A, Blue B, Orange C, Green D), up to four physically identical 16-way AS inline connectors can be used at the same harness split without any possibility of cross-mating during assembly, servicing, or post-event connector repair.

Contact Type — Pin (Male)

This listing is for the pin half of the 16-way AS inline pair — the active contact half — the pin terminals make physical contact with the socket terminals when mated, transferring electrical signals and power across the separable join. The corresponding socket half of the same circuit count and key colour is required to complete the mated connector pair. AS contacts are ordered separately — select the correct contact part number for your wire gauge and current requirements.

Technical Specifications

• Series: Deutsch Autosport AS
• Circuits: 16-way
• Configuration: Inline
• Contact type: Pin (Male)
• Key colour: Green (Key D)
• Shell material: Aluminium alloy
• Operating temperature: -65°C to +175°C
• Locking: Push-pull positive lock
• Typical application: Fourth connector in a complex multi-connector harness — providing a fourth unique key when four same-circuit-count as connectors are needed on one loom
