Deutsch Autosport AS 16-Way Flange — Pin (Male) — Red Key (N)
The Deutsch Autosport AS 16-Way Flange Pin (Male) Connector with Red (N) Keying Insert — SKU: AS020-16PN is a professional MIL-spec-grade Deutsch Autosport AS series connector for medium-complexity ECU sub-harness connectors, auxiliary PDM circuit interfaces, and multi-circuit sensor harness separable joins in race cars and high-performance vehicles across Norway, Sweden, and Denmark. Configured as a panel-mounted flange connector that bolts permanently to a chassis panel, bulkhead, or firewall — the fixed, chassis-anchored half that the cable-side plug mates into.
Deutsch Autosport AS 16-Way — 16-circuit Circuit Configuration
The Deutsch Autosport AS series is the professional standard circular connector format for motorsport wiring — aluminium alloy shell, gold-plated contacts, positive push-pull locking, and full MIL-spec environmental sealing for race-condition reliability. The 16-circuit configuration is used for ECU sensor sub-loom joins, PDM auxiliary circuit interfaces, and multi-circuit sensor harness separable points where the 12-way is insufficient in professional motorsport builds throughout Scandinavia. Versatile 16-circuit mid-range shell — suited to ecu sub-loom and pdm auxiliary interface separable joins.
Pin (Male) — 16-Circuit Contact Array
This is the pin half of the 16-way AS flange pair. Sixteen gold-plated pin contacts transfer sixteen individual circuits simultaneously — each contact making precision engagement with its socket terminal when the lock is engaged. The corresponding socket half of the same circuit count and key colour completes the mated pair — both halves are required. AS contacts are ordered separately; select the correct contact part number for your wire gauge and current requirements.
Red Key (N) — Keying Position and Mis-Mate Prevention
Red N is the neutral (non-keyed) specification — the correct choice when only a single 16-circuit AS flange is used at this separation point and no adjacent same-size connector creates a mis-mate risk. An N-keyed half mates with any other N-keyed half of the same circuit count, keeping the connector specification simple and straightforward for single-pair 16-circuit AS applications. Red N is also commonly used on initial harness prototype builds before the final keying strategy is confirmed, on harnesses where each AS connector is a unique circuit count (eliminating any possibility of mis-mating by design), and on any motorsport harness build in Norway, Sweden, or Denmark where keyed mis-mate prevention between same-circuit-count connectors is not required at this particular separation point.
Flange Configuration — Panel-Mounted Fixed Connector Point
The AS flange connector mounts permanently to a chassis panel, bulkhead, or firewall using the integrated mounting flange holes — creating a fixed 16-circuit connector point anchored to the vehicle structure. Once bolted in position, the flange remains in place throughout the vehicle’s service life while the matching plug half is mated and unmated repeatedly for component installation, removal, and servicing without disturbing the chassis-side connection.
The 16-circuit AS flange is used for medium-complexity ECU sub-harness connectors, auxiliary PDM circuit interfaces, and multi-circuit sensor harness separable joins across race cars and performance vehicles in Norway, Sweden, and Denmark. Flange connectors are the standard specification at firewall primary harness separation points, engine bay bulkhead connectors, chassis rail panel interfaces, and any harness separation point that aligns with a structural surface suitable for mounting. The fixed flange provides a permanent, precisely-located connector point that makes harness re-mating fast and repeatable at every race event service interval.
Technical Specifications
- Series: Deutsch Autosport AS
- Circuits: 16-way
- Configuration: Flange
- Contact type: Pin (Male)
- Key colour: Red (Key N)
- Shell material: Aluminium alloy
- Operating temperature: -65°C to +175°C
- Locking: Push-pull positive lock
- Typical application: Single-connector applications where no adjacent same-circuit-count connector creates a mis-mate risk
