Deutsch Autosport AS 10-Way Inline — Pin (Male) — Orange Key (C)
The Deutsch Autosport AS 10-Way Inline Pin (Male) Connector with Orange (C) Keying Insert — SKU: AS112-98PC is a professional MIL-spec-grade Deutsch Autosport AS series inline connector for ECU auxiliary sub-connector interfaces, multi-sensor harness separable joins, and compact motorsport loom separable points in race cars and high-performance vehicles across Norway, Sweden, and Denmark. Configured as an inline separable join — both halves are free, cable-mounted connectors within the wire run, creating a separable interface at any intermediate point in the harness without requiring a panel or bulkhead mounting point.
Deutsch Autosport AS 10-Way — Series Design and Circuit Count
The Deutsch Autosport AS series is the standard circular connector format for professional motorsport wiring — featuring an aluminium alloy shell machined to MIL-spec tolerances, gold-plated contact interfaces for low-resistance long-term electrical performance, and a positive push-pull locking mechanism that stays secure under sustained race vibration and rapid connector cycling at service intervals. The 10-way AS inline fits between the compact 8-way and the more common 12-way in circuit density — used for ECU auxiliary interfaces, multi-sensor harness separable joins, and motorsport loom separation points where a single connector is preferred over two smaller ones. The 10-way shell provides additional circuit capacity over the 8-way while remaining compact — suited for auxiliary ecu and pdm sub-circuit harness separable joins.
Pin (Male) — 10-Circuit Contact Array
This listing is the pin half of the 10-way AS inline pair. Ten pin contacts transfer ten individual circuits across this inline separable join — accommodating the full circuit count of ECU auxiliary sub-connectors and multi-sensor interfaces in a single mated connector pair. The corresponding socket half of the same circuit count and key colour is required to complete the mated connector pair — both halves must be ordered to form a functional inline separable join. AS contacts are ordered separately; select the correct contact part number for your wire gauge and current requirements.
Orange Key (C) — The third keying position in the deutsch as system
Orange C is the third key assignment in a harness requiring three 10-circuit AS inline connectors at the same separation point. Three-connector keying arrangements occur in the most complex full race car loom builds — where the total circuit count at an engine-to-chassis split requires three parallel 10-circuit bundles to carry the full harness across the separation point. With Yellow A, Blue B, and Orange C assigned across the three pairs, each bundle can only be reconnected to its correct counterpart, providing complete mis-mate protection across all three connectors. Scandinavian rally and endurance harness builders working on high-complexity full race looms reach for Orange C whenever a third 10-circuit AS inline join is required at the same separation point.
Inline Configuration — Flexible Harness Separation Without a Fixed Mount
The AS inline configuration places the separable join within the harness run itself — neither connector half is fixed to a panel or chassis surface. This makes it the preferred choice for engine-to-chassis harness separation points, subframe and removable component harness joins, and any separable interface along the wire run where flexible placement is required. The inline format is widely used across professional race car loom builds in Norway, Sweden, and Denmark for its placement flexibility and its clean, balanced appearance when both halves are routed through the same harness trunk or loom sleeve.
Technical Specifications
- Series: Deutsch Autosport AS
- Circuits: 10-way
- Configuration: Inline
- Contact type: Pin (Male)
- Key colour: Orange (Key C)
- Shell material: Aluminium alloy
- Operating temperature: -65°C to +175°C
- Locking: Push-pull positive lock
- Typical application: The third separable join in a complex loom with three or more connectors of the same circuit count
