Deutsch Autosport AS Mini 3-Way Inline — Socket (Female) — Yellow Key (A)
The Deutsch Autosport AS Mini 3-Way Inline Socket (Female) Connector with Yellow (A) Keying Insert — SKU: AS107-98SA is a professional MIL-spec-grade motorsport connector for compact 3-circuit connections. Configured as a in-line harness separable connector — this connector creates a separable join within the harness run — both halves are cable-mounted, allowing the harness to be split at any point along its run without a fixed panel or bulkhead mount. Designed for use in demanding race car, rally, and high-performance vehicle wiring harnesses across Norway, Sweden, and Denmark.
Deutsch Autosport AS Mini — Shell Design and Build Quality
The AS Mini shell is the most compact format in the Deutsch Autosport circular connector family — significantly smaller and lighter than the standard AS shell — making it the preferred choice wherever minimal connector size and weight are critical. Despite its compact dimensions, the AS Mini retains the full aluminium alloy shell construction, push-pull positive locking mechanism, and gold-plated contact interfaces of the larger AS series. 3-way is the smallest as mini configuration — ideal for simple sensor connections, single-actuator circuits, and compact harness separation points where only three circuits need to cross the separable join. The 3-way AS Mini is specified by professional race teams, ECU harness fabricators, and motorsport engineers for applications where a compact, high-integrity, serviceable separable connector is required at a harness split point.
Inline Configuration — Inline separable join — both halves are free, cable-mounted connectors
The inline configuration is chosen for harness separation points within the wire run — away from any panel or bulkhead surface. Both inline connector halves are free and cable-mounted, allowing the harness to be split cleanly at any intermediate point such as engine bay to chassis joins, subframe separable points, and removable component harness connections.
Contact Type — Socket (Female)
This listing is for the socket (socket) half of the 3-way pair. It mates with the corresponding pin half of the same circuit count and key colour. Both halves are required to form a complete mated connector pair. AS Mini contacts are ordered separately — select the correct contact part number for your wire gauge.
Yellow Key (A) — Mis-Mate Prevention
This connector is fitted with a Yellow (A) keying insert — the first standard keying position — Yellow A is the most widely specified starting key when multiple same-circuit-count connectors appear on a single harness, ensuring each connector pair can only mate with its correct counterpart. The physical keying tab prevents mating with any other AS Mini 3-way connector carrying a different key colour — eliminating incorrect connection errors during installation or servicing of complex race car electrical systems in Norway, Sweden, and Denmark.
Technical Specifications
- Series: Deutsch Autosport AS Mini
- Circuits: 3-way
- Configuration: Inline
- Contact type: Socket (Female)
- Key colour: Yellow (Key A)
- Shell material: Aluminium alloy
- Operating temperature: -65°C to +175°C
- Locking: Push-pull positive lock
