ALUMINUM COATED FIBERGLASS SLEEVE 1/2″

Textalu 1/2″ Aluminium-Coated Fiberglass Heat Sleeve — Motorsport Harness Radiant Heat Protection

The TX-1202-12 is a Textalu aluminium-coated fibreglass heat sleeve in 1/2″ (approximately 12.7 mm internal diameter). Textalu sleeve provides radiant heat protection for motorsport wiring harnesses in engine bay environments, combining a high-temperature fibreglass braid structure with an aluminium foil outer coating that reflects infrared radiation away from the wiring inside. This sleeve is suited to medium wire bundles and primary sub-harness runs in engine bay heat zones.

How Textalu Sleeve Works — Radiant Heat Reflection

Heat reaches a wire harness in two primary ways: conduction (direct contact with a hot surface) and radiation (infrared energy emitted from a hot surface without contact). Standard protective sleeving addresses conduction and abrasion but provides little protection against radiated heat from exhaust manifolds, turbocharger housings, and catalytic converters — sources that can raise wire insulation temperature significantly even without direct contact. The Textalu aluminium coating reflects a large proportion of incident infrared radiation back toward the heat source, dramatically reducing the thermal load on the wire insulation inside the sleeve compared to an unprotected or fibreglass-only sleeved harness routed in the same location.

Textalu vs FireFlex — Choosing the Right Product

Both Textalu and FireFlex provide protection in high-temperature engine bay environments, but their mechanisms differ. FireFlex (silicone-coated fibreglass) provides excellent conduction resistance and modest IR reflection from a flexible, self-closing format. Textalu provides maximum infrared reflection from its aluminium surface but requires a closure method (heat shrink end caps or tie-wraps) to secure it over the harness. For locations where radiated heat from nearby exhaust is the dominant thermal challenge, Textalu is the correct specification; for locations where direct heat conduction from contact with hot surfaces is the primary concern, FireFlex or the DragonSleeve format is more appropriate.

1/2″ Size — Application Range

The 1/2″ internal diameter suits medium wire bundles and primary sub-harness runs in engine bay heat zones. Textalu sleeve should be sized to slide freely over the wire bundle — a tight fit prevents installation and does not leave the protective air gap that contributes to the sleeve’s thermal insulation performance.

Available from Arctic Performance Parts

Arctic Performance Parts stocks Textalu aluminium-coated fibreglass sleeve from 1/4″ to 7/8″ to support motorsport harness heat protection builds across Norway, Sweden, and Denmark. Lead time 1–2 weeks for quantities beyond current stock.
