HD Tin-Plated Eyelet — 8 AWG / #10 screw
The 8 AWG Tin Plated Eyelet #10 Stud — SKU: 810TP is a heavy-duty tin-plated copper eyelet terminal for 8 AWG large-gauge cable, providing a reliable, corrosion-resistant crimp termination for motorsport battery wiring, alternator output feeds, earth straps, and high-current power distribution in race car and performance vehicle electrical systems. The tin plating over the copper barrel and eyelet ring suppresses oxidation at both the crimp interface and stud contact face, ensuring stable, low-resistance connections throughout the terminal’s service life.
8 AWG — Gauge Selection
8 AWG is a mid-heavy gauge used for primary fuel pump feeds, high-current cooling fan power, electric water pump circuits, and secondary distribution branches in race car systems. The 810TP crimp barrel is sized precisely for 8 AWG conductor cross-section — ensuring full barrel fill during crimping for maximum mechanical retention and minimum contact resistance.
#10 screw Stud — Fixing Size
The #10 screw hole is used on relay module bases, component terminal blocks, and distribution panel studs where #10 hardware is the specified fixing. Verify the stud or bolt diameter at the target connection point before ordering to ensure correct fit and adequate contact surface area at the power circuit join.
Tin Plating — Joint Integrity
Bare copper terminals oxidise when exposed to heat cycling, moisture, and the chemically active atmosphere of a race engine bay. Oxidation increases resistance, generates heat under load, and accelerates joint degradation. The tin plating on the 810TP resists oxidation far longer than bare copper, maintaining joint quality across a full racing season and multiple years of competitive use.
Technical Specifications — SKU 810TP
- Wire gauge: 8 AWG
- Stud size: #10 screw
- Plating: Tin over copper
- Terminal type: Eyelet / ring lug (HD)
- Termination: Crimp (hydraulic or heavy-duty crimping tool)
- Application: Relay output terminal connections, component-mounted power terminal blocks, and distribution panel positions for 8 AWG cable.
- Category: HD Lugs / Eyelets
